ShadowDusk

A cross-platform HLSL shader compiler for MonoGame, KNI, and FNA. Compile .fx shaders to .mgfx (MonoGame/KNI) or .fxb (FNA) on Linux, macOS, or Windows — no Wine, no Windows SDK, no fxc.exe, no DirectX install required.

The "XNA-likes." Throughout these docs, MonoGame, KNI, and FNA — the XNA-derived runtimes ShadowDusk targets — are collectively the XNA-likes. Classic Microsoft XNA 4.0 itself is out of scope (a different, abandoned, Windows-only toolchain). The three share a heritage but not one effect format: MonoGame and KNI load the .mgfx (MGFX) container, while FNA loads the legacy D3D9 fx_2_0 .fxb — so where the output format matters, the docs name the runtime explicitly rather than say "XNA-likes."

The product is the in-memory IShaderCompiler library (the ShadowDusk.Compiler NuGet package): add the package and call CompileAsync(fx) to get the compiled effect bytes (.mgfx, or .fxb for FNA) — nothing else to install. The CLI (mgfxc dotnet tool) is a delivery shape of the same library for build-time use (an MGCB plugin is a future scaffold, not yet shipped). The in-browser shader fiddle is only a sample of reach — not a separate product.

What it does

MonoGame's stock content pipeline shells out to mgfxc, a Windows-only tool that depends on fxc.exe from the DirectX SDK. ShadowDusk replaces that step with one portable pipeline whose output a real XNA-like Effect — MonoGame, KNI, or FNA — loads and renders like the reference compiler's (mgfxc for MonoGame/KNI, fxc for FNA):

OpenGL / WebGL  (MonoGame, KNI):
  HLSL (.fx)
    → DXC (via Vortice.Dxc)  →  SPIR-V
    → SPIRV-Cross             →  GLSL (+ MojoShader-dialect rewrite)
    → .mgfx binary            →  MonoGame / KNI Effect loader

DirectX (DX11)  (MonoGame, KNI):
  HLSL (.fx)
    → vkd3d-shader            →  DXBC (SM5)
    → .mgfx binary            →  MonoGame / KNI Effect loader

FNA  (D3D9 fx_2_0):
  HLSL (.fx)
    → vkd3d-shader            →  D3D9 fx_2_0 bytecode (SM ≤ 3)
    → .fxb binary             →  FNA Effect loader (MojoShader)

OpenGL / WebGL is fully cross-platform and self-contained (DXC + SPIRV-Cross ride inside the package). For DirectX (DX11), ShadowDusk produces DXBC in-process via two backends behind IDxbcShaderCompiler, chosen by CompilerOptions.DxbcBackend: the default, cross-platform vkd3d-shader (DxbcBackend.Vkd3d), whose per-RID natives ship inside the package and run on Linux/macOS/Windows, and the opt-in d3dcompiler_47 (Microsoft's HLSL compiler — a Windows-only system DLL; the most fxc-faithful correctness oracle). DXC is not used for DX11 (it emits DXIL/SM6, not the DXBC/SM ≤ 5 the DX11 runtime loads). See The Faithful Pipeline and DirectX DXBC (vkd3d) Path.

Supported backends

Backend Output Status
OpenGL / DesktopGL GLSL Validated end-to-end (10/10 in real MonoGame DesktopGL)
DirectX (DX11) DXBC (SM5) via vkd3d-shader (default, cross-platform) / d3dcompiler_47 (Windows-only oracle, opt-in) Validated end-to-end (10/10 in real MonoGame WindowsDX)
WebGL (XNA Fiddle / KNI browser) GLSL ES Validated end-to-end (10/10 in real headless KNI WebGL)
FNA (/Profile:FNA → .fxb) D3D9 fx_2_0 via vkd3d-shader Validated end-to-end (pixel-identical to fxc /T fx_2_0 in real FNA — PS-only and custom-vertex-shader effects, incl. multi-pass + in-pass render states)
Metal (macOS / iOS) MSL Not yet implemented (future)
Vulkan SPIR-V Future

The table above is the graphics-backend axis — the one that decides the output bytes for MonoGame/KNI. Framework is a separate axis: MonoGame and KNI read the same MGFX format (both supported); FNA is also supported, but via a different effect path — ShadowDusk emits the legacy D3D9 fx_2_0 .fxb (MojoShader) FNA loads, not the MGFX container; classic Microsoft XNA 4.0 is out of scope. New to picking a target, or building a shader-download feature? See Choosing a Target — it covers the framework / backend / GraphicsProfile axes and the .mgfx-vs-.xnb distinction.

"Same .mgfx as mgfxc" means behaviorally equivalent and Effect-loadable — it renders the same pixels in the real runtime. Byte-identity is only ShadowDusk's own reproducibility (same version + source + target → same bytes), never byte-equality with mgfxc.

Output container. The default is MGFX v10 — it loads on every MonoGame 3.8.2+ and KNI runtime, so you never set a flag for correct output. Opt-in/experimental MGFX v11 (CompilerOptions.MgfxVersion = 11, MonoGame 3.8.5+) and KNIFX v11 (CompilerOptions.Container = EffectContainer.Knifx, KNI v4.02+) containers are additionally available, both render-proven in their real engines. See Parameters & Caveats.

In-memory in five lines

using ShadowDusk.Compiler;
using ShadowDusk.Core;

var compiler = new EffectCompiler();
Result<CompiledShader, ShaderError[]> result =
    await compiler.CompileAsync(hlslSource, new CompilerOptions { Target = PlatformTarget.OpenGL });

if (result.IsSuccess)
{
    byte[] mgfx = result.Value.Data;   // .mgfx, ready for new Effect(graphicsDevice, mgfx)
}

See the In-Memory Quickstart for the full walkthrough (and the default-target caveat between the library and the CLI).

Design principles

  • No Windows / Wine requirement. Every native binary has Linux + macOS builds; the pieces the pipeline needs ride inside the package.
  • Drop-in replacement. Same CLI flags, same .mgfx output format, same exit codes and error format as mgfxc. Zero changes to existing content pipelines.
  • Deterministic output. Same source + same target = byte-identical .mgfx, given the same compiler version (ShadowDusk's own reproducibility).
  • Fail loudly. Shader errors surface the source file, line, column, and message exactly as the underlying compiler emitted them.
  • Result-typed errors. No exceptions for expected shader failures — the API returns Result<CompiledShader, ShaderError[]>.

The repository README.md is the front door and stays the source of truth for the project summary, the backend matrix, and acknowledgements; this site documents the product, its delivery shapes, samples, and API in depth.
